ABB SPST120R Power Brkii Shunt Trip 120Ac/125Dc - Advanced Remote Control Module for Circuit Breakers, Supports Up to 800A
ABB
$2,367.38
The ABB SPST120R Pwr Brkii Shunt Trip 120Ac/125Dc is an advanced electronic module designed to enhance the functionality of your circuit breaker by providing remote control capabilities. This shunt trip accessory allows for the seamless opening of the circuit breaker by sending a precise signal to the trip unit. Once activated, it enables the trip unit to record, display, and communicate the opening event, especially in MicroVersaTrip PM trip units, ensuring that the event was initiated by the shunt trip device. With a continuous rating and no need for a cut-off switch, the shunt trip is both reliable and efficient. When energized, it supplies +24 Vdc power to the trip unit, ensuring the display remains powered. This model supports 120R Amps and is capable of handling up to 800 A, making it a robust solution for your power management needs.
- Sub Brand:
- Spectra RMS, Mag-Break
- Standard:
- E11592
- Frame:
- SK1200
- Amperage Rating:
- 800A
- Spec Sheet:
- View
