Description
Overview
Abb
General Purpose Transformers, T Series
Item# Tc2200F - Transformer, 200Va, 1-Ph, Open, Ce Pri: 120X240V, Sec: 24V Ce Marked, Less Fuseclips, Touchsafe
T Series Information
- 45~5000 Va
- Multple Primary Ac Voltages
- 24/120 Volts Ac Secondaries
- Epoxy Encapsulated Coils
- Ul E175311
- Available With Terminal Covers Through 750 Va.
- Fuse Blocks Included On Some Models
- Ce Compliance On Some Models
- Molded-In Terminals
Specifications
Item Number: &Nbsp;
Tc2200F
Upc: &Nbsp;
804325324076
Brand:
Abb
Item Category:
Transformers
Subcategory:
General Purpose Transformers
Series:
T
Type:
Control
Phase:
1
Va Rating:
200 Volt-Amps
Primary Voltage:
120/240
Secondary Voltage:
24
Enclosed:
No
Primary Fuseholder:
Not Available
Secondary Fuseholder:
Not Available
Termination:
Integrally Molded Terminal Blocks
Terminal Covers:
Yes
Insulation Class:
105
Temperature Rise (F):
131 Degrees F
Comments:
Fuses And Fuse Holders Sold Separately. Ip20 Touch Safe Covers Included.
Circuit Diag. No.:
Abbg_Xfmr_Tc2_50-750
Diag. No.:
Abbg_Xfmr_Tc_24
Picture No.:
Abbg_Xfmr_Tc
H X W X D:
4 In X 4.5 In X 4.38 In
&Nbsp;&Nbsp;Net Weight:
8 Lb 13 Oz
&Nbsp;&Nbsp;Gross Weight:
1 Lb
