Description
Overview
ABB
General Purpose Transformers, T Series
Item# TC307521 - TRANSFORMER, 75VA, 1-PH, OPEN PRI: 380x400x415V, SEC: 110x220V CE MARKED, LESS FUSECLIPS, TOUCHSAFE
T Series Information
- 45~5000 va
- Multple Primary AC Voltages
- 24/120 Volts AC Secondaries
- Epoxy Encapsulated Coils
- UL E175311
- Available with Terminal Covers through 750 va.
- Fuse Blocks Included on Some Models
- CE Compliance on Some Models
- Molded-in Terminals
Specifications
Item Number:
TC307521
UPC:
662019649245
Brand:
ABB
Item Category:
Transformers
Subcategory:
General Purpose Transformers
Series:
T
Type:
Control
Phase:
1
VA Rating:
75 Volt-Amps
Primary Voltage:
380/400/415
Secondary Voltage:
110/220
Enclosed:
No
Primary Fuseholder:
Not Available
Secondary Fuseholder:
Not Available
Termination:
Integrally Molded Terminal Blocks
Terminal Covers:
Yes
Insulation Class:
105
Temperature Rise (F):
131 Degrees F
Comments:
Fuses and fuse holders sold separately. IP20 touch safe covers included.
Circuit Diag. No.:
ABBG_XFMR_TC3_50-750
Diag. No.:
ABBG_XFMR_TC3_110_220
Picture No.:
ABBG_XFMR_TC
H x W x D:
3.25 in x 3.55 in x 3.35 in
Net Weight:
1 lb
Gross Weight:
1 lb
