Baumer FLDK 110C1005/S42 11100809
Baumer
The Baumer FLDK 110C1005/S42 11100809 is a high-performance sensor designed for precise edge detection and counting applications in fast-moving environments. It features a measuring distance of 0 to 120 mm with an optimal operating distance of 100 mm, and can handle counting rates up to 600,000 copies per hour. The sensor operates effectively with object speeds up to 5 m/sec and a minimum object cycle distance of 1 mm. It is equipped with a pulsed red laser diode light source, emitting a visible red laser line of 3 mm at a wavelength of 670 nm, and falls under Laser class 2 for safety. Key features include an LED yellow edge indicator, LED green power indication, and options for false pulse suppression and sensitivity adjustment. The output pulse length is selectable among 5, 10, 15, or 20 ms, ensuring adaptability to different application requirements. The sensor also offers protection features such as short circuit and reverse polarity protection. Physically, the sensor has a rectangular design with a width/diameter of 30 mm, housed in durable PA 6 material with a glass front optics. It connects via a DIN 45322, 6-pin connector and operates within a voltage supply range of 10 to 30 VDC. The current consumption maxes out at 180 mA with no load. Suitable for operating temperatures ranging from 0 to +50 °C, it is rated at protection class IP 54, making it robust against dust and splashing water.
- Measuring distance Sd:
- 16 120 mm
- Beam diameter:
- 0.9 0.5 mm
- Adjustment:
- Teach-in: button / external
- Teach-in range min.:
- > 2 mm
- Power on indication:
- LED green
- Soiled lens indicator:
- LED red
- Resolution:
- 2 120 µm
- Linearity error:
- ± 0.015 0.35 mm
- Beam type:
- Point
- Interference suppression:
- < 30 ms
- Temperature drift:
- < 0,06 % Sde/KLight source=Pulsed red laser diode
- Wave length:
- 650 nm
- Laser class:
- 2
- Response time / release time:
- < 0.9 ms
- Voltage supply range +Vs:
- 12 28 VDC
- Current consumption max. (no load):
- 100 mA
- Output circuit:
- Analog
- Output signal:
- 4 ... 20 mA
- Load resistance:
- < (+Vs - 6 V) / 0,02 A
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes, Vs to GND
- Width / diameter:
- 12.4 mm
- Height / length:
- 37 mm
- Depth:
- 34.5 mm
- Design:
- Rectangular
- Housing material:
- Die-cast zinc
- Front (optics):
- Glass
- Connection types:
- Connector M8 4 pin
- Ambient light immunity:
- < 30 kLux
- Protection class:
- IP 67
- Operating temperature:
- 0 +50 °C
- Datasheet:
- View;
- QN-QUOTE-REQUEST:
- true
