The Baumer FSF 050A1002 10210319 is a through-beam type fiber optic sensor with a cylindrical threaded head made of brass. It features an operating range of 450 mm and can withstand temperatures from -25 to +250 °C. The sensor has a 60° exit angle and is compatible with infrared light at 1450 nm. It does not have an integrated lens but supports adaptable lenses. The fiber optics are not designed to be shortened but boast a robust design with a brass chromium-plated cable jacket and a glass fiber optic cable measuring 50 cm in length. The head dimensions are 4 mm in width/diameter and 26 mm in height/length, with an M4 x 0.7 thread. The bending radius is 15 mm when fixed and 30 mm when mobile.
- Operating principle:
- Through-beam type
- Actual range Sb:
- 450 mm
- Fiber optic head:
- Cylindrical threaded
- Operating temperature:
- -25 +250 °C
- Exit angle:
- 60°
- Fiber optics can be shortened to length:
- No
- Integrated lens:
- No
- Adaptable lens:
- Yes
- Infrared light compatibility (1450 nm):
- YesWidth / diameter (head)=4 mm
- Height / length (head):
- 26 mm
- Material (head):
- Brass
- Thread:
- M4 x 0.7
- Bending radius (fixed):
- 15 mm
- Bending radius (mobile):
- 30 mm
- Cable jacket diameter:
- 5 mm
- Material cable jacket:
- Brass chromium plated
- Fiber cross section:
- 2 mm²
- Material (fiber optic cable):
- Glass
- Length (fiber optic cable):
- 50 cm
