The Baumer FUF 050B1005 10213828 is a diffuse type fiber optic sensor with a sensing distance of 60 mm. It features a cylindrical threaded fiber optic head made of brass, measuring 4 mm in width and 26 mm in length. The sensor operates within a temperature range of -25 to +250 °C and has an exit angle of 60°. It is compatible with infrared light at 1450 nm but does not support adaptable or integrated lenses. The fiber optic cable, made of glass, is 50 cm long with a cross section of 1 mm² and is encased in a brass chromium-plated jacket. The fixed bending radius is 15 mm, and the mobile bending radius is 30 mm. The cable jacket diameter is 5 mm, and the thread size is M4 x 0.7.
- Operating principle:
- Diffuse type
- Sensing distance Tw:
- 60 mm
- Fiber optic head:
- Cylindrical threaded
- Operating temperature:
- -25 +250 °C
- Exit angle:
- 60°
- Fiber optics can be shortened to length:
- No
- Integrated lens:
- No
- Adaptable lens:
- No
- Infrared light compatibility (1450 nm):
- YesWidth / diameter (head)=4 mm
- Height / length (head):
- 26 mm
- Material (head):
- Brass
- Thread:
- M4 x 0.7
- Bending radius (fixed):
- 15 mm
- Bending radius (mobile):
- 30 mm
- Cable jacket diameter:
- 5 mm
- Material cable jacket:
- Brass chromium plated
- Fiber cross section:
- 1 mm²
- Material (fiber optic cable):
- Glass
- Length (fiber optic cable):
- 50 cm
- Datasheet:
- View
