Baumer IFRM 03N3501/KS35L 10139549
Baumer
$274.80
The Baumer IFRM 03N3501/KS35L 10139549 is a flush-mounted inductive sensor with a nominal sensing distance of 0.8 mm and adjustable hysteresis between 2% and 20% of Sr. It features a red LED output indicator and operates at a switching frequency of 3 kHz. The sensor is designed for a voltage supply range of 6 to 30 VDC and has a maximum current consumption of 12 mA when no load is present. It includes an NPN break function (NC) output circuit, with a voltage drop of less than 2 VDC and an output current capacity of 100 mA. Enhanced with both short circuit and reverse polarity protection, this sensor is built with a POM sensing face and a stainless steel housing, measuring 3 mm in diameter and 22 mm in length. It connects via a flylead connector M8 and operates within a temperature range of -25 to +75 °C. The sensor is IP 67 rated, ensuring protection against dust and immersion. For more details, you can [View the datasheet](https://www.baumer.com/medias/__secure__/Baumer_IFRM-03N3501-KS35L_EN_20221109_DS.pdf?mediaPK=9055866355742).
- Mounting type:
- Flush
- Nominal sensing distance Sn:
- 0.8 mm
- Hysteresis:
- 2 20 % of Sr
- Output indicator:
- LED red
- Switching frequency:
- 3 kHz
- Voltage supply range +Vs:
- 6 30 VDC
- Current consumption max. (no load):
- 12 mA
- Output circuit:
- NPN break function (NC)
- Voltage drop Vd:
- <2 VDC
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Design:
- Cylindrical smooth
- Material (sensing face):
- POM
- Housing material:
- Stainless steel
- Dimension:
- 3 mm
- Housing length:
- 22 mm
- Connection types:
- Flylead connector M8
- Operating temperature:
- -25 +75 °C
- Protection class:
- IP 67
- Datasheet:
- View
