The Baumer IWFK 20Z8704/S35A 10155694 is a quasi-flush, linearized inductive sensor with a measuring distance of 0 to 10 mm and high resolution and repeat accuracy of less than 0.01 mm and 0.015 mm respectively. It features a linearity error of ± 50 µm and minimal temperature drift of ± 5% (Full Scale). The sensor offers fast response times of less than 2.5 ms (factory characteristic) and less than 3.1 ms (teach-in characteristic), and operates with a voltage supply range of 15 to 30 VDC. It includes an analog output of 0 to 10 VDC and supports a load resistance of over 1000 Ohm. The sensor is equipped with short circuit and reverse polarity protection, housed in a durable polyester body with a PBT sensing face, and connects via an M8 connector. Suitable for operating temperatures from -10 to +70 °C, it is designed for robust applications with an IP 67 protection class.
- Particular characteristics:
- Smooth sensing head Side view
- Operating principle:
- Diffuse type
- Sensing distance Tw:
- 30 mm
- Fiber optic head:
- Cylindrical smooth, side view
- Operating temperature:
- -25 +70 °C
- Exit angle:
- 60°
- Fiber optics can be shortened to length:
- No
- Integrated lens:
- No
- Adaptable lens:
- No
- Infrared light compatibility (1450 nm):
- YesWidth / diameter (head)=4 mm
- Height / length (head):
- 16 mm
- Material (head):
- Aluminum
- Bending radius (fixed):
- 7.5 mm
- Bending radius (mobile):
- 15 mm
- Cable jacket diameter:
- 2.5 mm
- Material cable jacket:
- PVC
- Fiber cross section:
- 0.5 mm²
- Material (fiber optic cable):
- Glass
- Length (fiber optic cable):
- 100 cm
- Datasheet:
- View
