The Baumer O200.RP-GW1J.72CV 11210550 is a retro-reflective sensor equipped with a pulsed PinPoint LED light source, offering a nominal range of 4 meters and an actual range of 3 meters. It can detect objects as small as 4 mm, thanks to its precise alignment capabilities and polarization filter. The sensor features a flashing output indicator for alignment or soiled lens detection, and LED indicators for power status and output. It supports sensitivity adjustment via Teach-in and IO-Link, operates within a voltage supply range of 10 to 30 VDC, and consumes a maximum of 40 mA at 10 VDC. The sensor's output function can be set to light or dark operate, and it includes push-pull output circuitry with a maximum output current of 50 mA. It offers protection against short circuits and reverse polarity, and is housed in a durable plastic casing with a smooth stainless steel sleeve for mechanical mounting. The sensor is designed for operating temperatures ranging from -25 to +50 °C and is rated IP 67 for protection against dust and water ingress. It connects via a 4-pin, 2-meter PVC cable and is ideal for various detection applications requiring high precision and reliability.
- Type:
- Retro-reflective sensor
- Light source:
- Pulsed PinPoint LED
- Actual range Sb:
- 3 m
- Nominal range Sn:
- 4 m
- Smallest object recognizable typ.:
- 4 mm (FTAR 013A000)
- Polarization filter:
- Yes
- Alignment / soiled lens indicator:
- Flashing output indicator
- Output indicator:
- LED yellow
- Power on indication:
- LED green
- Sensitivity adjustment:
- Teach-in and IO-Link
- Wave length:
- 644 nm
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 1,5°
- Response time / release time:
- < 0.25 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 40 mA (@ 10 VDC)
- Current consumption typ.:
- 16 mA (@ 24 VDC)
- Voltage drop Vd:
- <2 VDC
- Output function:
- Light / dark operate
- Output circuit:
- Push-pull
- Output current:
- 50 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 8 mm
- Height / length:
- 25.1 mm
- Depth:
- 15.8 mm
- Design:
- Rectangular
- Mechanical mounting:
- Sleeve smooth (stainless steel)
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Cable 4 pin, 2 m
- Cable characteristics:
- PVC / PVC 4 x 0.08 mm²
- Operating temperature:
- -25 +50 °C
- Protection class:
- IP 67
