Baumer O200.ZR-GW1J.72NV/E026_H006 11231264

The Baumer O200.ZR-GW1J.72NV/E026_H006 11231264 is an intensity difference sensor with a sensing distance of 20 to 200 mm and can recognize objects as small as 2 mm at 100 mm. It features a green LED for power indication and a yellow LED output indicator that flashes when alignment is needed or the lens is soiled. The sensor offers both Teach-in and IO-Link options for sensing distance adjustment and includes suppression of reciprocal influence. It uses a pulsed red LED light source with a wavelength of 644 nm and has a quick response time of less than 0.25 ms. The sensor operates on a voltage supply range of 10 to 30 VDC and has a maximum current consumption of 40 mA at 10 VDC. It features light/dark operate output functions, a push-pull output circuit, and can handle an output current of 50 mA. Safety features include short circuit and reverse polarity protection. The sensor's compact design measures 8 mm in width, 25.1 mm in height, and 15.8 mm in depth, with a rectangular shape and threaded sleeves M3 for mechanical mounting. It is made from durable plastic materials (ASA, PMMA) with a PMMA front optics. The sensor is equipped with a Flylead connector M8 4 pin and has a PVC cable. It is rated IP 67 for protection against dust and water ingress and can operate in temperatures ranging from -25 to +50 °C.
