Baumer O330.TP-ZZZZZ.72ZV/H006
Baumer
The Baumer O330.TP-ZZZZZ.72ZV/H006 is a through beam sensor designed as an emitter with a pulsed PinPoint LED light source. It offers an actual range of 10 meters and a nominal range of 12 meters. The sensor features a green LED power indication and operates at a wavelength of 634 nm. Its alignment accuracy is within 1.5 degrees. This model requires a voltage supply range of 10 to 30 VDC and has a maximum no-load current consumption of 50 mA, with a typical consumption of 25 mA. It includes reverse polarity protection and is housed in a rectangular, plastic body (ABS, ASA, PMMA) with dimensions of 11 mm in width, 32 mm in length, and 21 mm in depth. The sensor is mechanically mounted using threaded sleeves M3 (brass) and has a PMMA front optics. It connects via a 4-pin, 2-meter PVC cable. Suitable for operating temperatures between -25 to +55 °C, it boasts an IP 67 protection class and can be stored at temperatures ranging from -40 to +70 °C.
- Type:
- Through beam sensor
- Emitter / receiver:
- Emitter
- Light source:
- Pulsed PinPoint LED
- Actual range Sb:
- 10 m
- Nominal range Sn:
- 12 m
- Power on indication:
- LED green
- Wave length:
- 634 nm
- Alignment optical axis:
- < 1,5°
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 50 mA
- Current consumption typ.:
- 25 mA
- Reverse polarity protection:
- Yes
- Width / diameter:
- 11 mm
- Height / length:
- 32 mm
- Depth:
- 21 mm
- Design:
- Rectangular
- Mechanical mounting:
- Threaded sleeves M3 (brass)
- Housing material:
- Plastic (ABS, ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Cable 4 pin, 2 m
- Cable characteristics:
- PVC / PVC 4 x 0.14 mm²
- Operating temperature:
- -25 +55 °C
- Protection class:
- IP 67
- Storage temperature:
- -40 +70 °C
