The Baumer O500.SP-GW1B.72OU is a standard object detection light barrier equipped with a pulsed PinPoint LED light source with a wavelength of 630 nm. It features a background position from 60 to 600 mm and a scanning range of 90% to 85% of the background position. The device offers quick response and release times of less than 0.49 ms, and operates within a voltage supply range of 10 to 30 VDC. It includes a green LED for power indication and a yellow LED as a light indicator. Sensing distance can be adjusted via qTeach or externally. The unit is designed to suppress reciprocal influence and has an alignment accuracy of less than 1°. It supports both light and dark operating modes with a push-pull output circuit and can handle an output current of up to 100 mA. Safety features include short circuit and reverse polarity protection. The sensor is housed in a rectangular, plastic body (ASA, PMMA) with PMMA optics, measures 18 mm in width, 45 mm in height, and 32 mm in depth, and is connected via a flylead connector M12. It is rated IP 67 for protection against dust and water ingress and can operate in temperatures ranging from -25 to +60 °C.
- Type:
- Light barrier
- Version:
- Standard object detection
- Background position Sde:
- 60 600 mm
- Scanning range Sa:
- 90% ... 85% Sde
- Power on indication:
- LED green
- Light indicator:
- LED yellow
- Sensing distance adjustment:
- qTeach / external
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 1°Light source=Pulsed PinPoint LED
- Wave length:
- 630 nm
- Response time / release time:
- < 0.49 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 40 mA
- Current consumption typ.:
- 30 mA
- Voltage drop Vd:
- <3 VDC
- Output function:
- Light / dark operate
- Output circuit:
- Push-pull
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 18 mm
- Height / length:
- 45 mm
- Depth:
- 32 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Flylead connector M12, L=200 mm
- Protection class:
- IP 67
- Operating temperature:
- -25 +60 °C
