The Baumer OADM 20I5560/S14C 11164059 is a high-precision optical distance sensor with a measuring range of 30 to 130 mm. It features a pulsed red laser diode with a wavelength of 650 nm and a fast response time of less than 10 ms. The sensor offers a resolution between 50 to 70 µm and a linearity error of ±0.15 to 0.22 mm. It includes a green LED for power indication and a red LED for soiled lens alert. The device operates on a 12 to 28 VDC supply and consumes a maximum of 100 mA with no load. It provides an analog output signal of 4 to 20 mA and includes short circuit and reverse polarity protection. The sensor's robust die-cast zinc housing and glass optics are designed to withstand harsh environments, certified with an IP67 protection rating. It operates effectively within a temperature range of 0 to +50 °C and features a compact design with dimensions of 20.6 mm in width, 65 mm in height, and 50 mm in depth. The connection is facilitated via a rotatable M12 5-pin connector.
- Measuring distance Sd:
- 30 130 mm
- Adjustment:
- No
- Power on indication:
- LED green
- Soiled lens indicator:
- LED red
- Resolution:
- 50 70 µm
- Linearity error:
- ± 0.15 0.22 mm
- Beam type:
- Line
- Beam width:
- 2 1 mm
- Beam height:
- 3 5 mm
- Temperature drift:
- < 0,03 % Sde/KLight source=Pulsed red laser diode
- Wave length:
- 650 nm
- Response time / release time:
- < 10 ms
- Voltage supply range +Vs:
- 12 28 VDC
- Current consumption max. (no load):
- 100 mA
- Output circuit:
- Analog
- Output signal:
- 4 ... 20 mA
- Load resistance (analog I):
- < (+Vs - 6 V) / 0,02 A
- Alarm output:
- PNP
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes, Vs to GND
- Width / diameter:
- 20.6 mm
- Height / length:
- 65 mm
- Depth:
- 50 mm
- Design:
- Rectangular
- Housing material:
- Die-cast zinc
- Front (optics):
- Glass
- Connection types:
- Connector M12 5 pin, rotatable
- Protection class:
- IP 67
- Operating temperature:
- 0 +50 °C
