Baumer

Baumer OHDM 16N5001/S14 10241873

(No reviews yet) Write a Review

Write a Review

Baumer

Baumer OHDM 16N5001/S14 10241873

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

10241873

UPC:

MPN:

10241873

Condition:

New

Type:

Background suppression

Sensing distance Tw:

25 … 300 mm

Sensing range Tb (at Tw max.):

40 … 300 mm

Sensing range Tb (at Tw min.):

5 … 25 mm

Repeat accuracy:

< 0.1 mm at laser focus

Output indicator:

LED yellow

Sensing distance adjustment:

Mechanical, 8 turn

Distance to focus:

80 mm

Suppression of reciprocal influence:

YesLight source=Pulsed red laser diode

Laser class:

2

Wave length:

650 nm

Response time / release time:

< 0.6 ms

Voltage supply range +Vs:

10 … 30 VDC

Current consumption max. (no load):

35 mA

Current consumption typ.:

25 mA

Voltage drop Vd:

<2 VDC

Output function:

Light / dark operate

Output circuit:

NPN

Output current:

200 mA

Short circuit protection:

Yes

Reverse polarity protection:

Yes

Width / diameter:

15.4 mm

Height / length:

50 mm

Depth:

50 mm

Design:

Rectangular

Housing material:

Die-cast zinc

Front (optics):

Glass

Connection types:

Connector M12 4 pin

Protection class:

IP 67

Operating temperature:

-10 … +50 °C

Datasheet:

View
