Baumer OHDM 20P6990/S14C 10153490

Baumer OHDM 20P6990/S14C 10153490

Baumer
SKU:
10153490
Availability:
Contact us to confirm availability and lead times.
$2,971.00
Condition:
New
Current Stock:
Description
Baumer OHDM 20P6990/S14C 10153490 is a background suppression sensor with a sensing distance ranging from 210 to 1500 mm and a beam diameter of 2 mm. It features a pulsed red laser diode light source, operating in laser class 2 with a wavelength of 650 nm. The sensor has quick response and release times of less than 6 ms and 18 ms respectively. It supports a voltage supply range of 12 to 28 VDC and has a maximum current consumption of 100 mA. The sensor includes both light and dark operating modes, with a PNP output circuit and an output current of 20 mA. It offers short circuit and reverse polarity protection. The device is housed in a rectangular, die-cast zinc body with glass optics, measuring 20.6 mm in width, 65 mm in height, and 50 mm in depth. It connects via an M12 5-pin connector and is rated IP 67 for protection against dust and water ingress, suitable for operating temperatures from 0 to +50 °C.
Additional Information
Type:
Background suppression
Sensing distance Tw:
210 … 1500 mm
Sensing range Tb (at Tw max.):
200 … 1500 mm
Sensing range Tb (at Tw min.):
200 … 210 mm
Power on indication:
LED green
Light indicator:
LED red
Sensing distance adjustment:
Teach-in
Beam diameter:
2 mmLight source=Pulsed red laser diode
Laser class:
2
Wave length:
650 nm
Response time:
< 6 ms
Release time:
< 18 ms
Voltage supply range +Vs:
12 … 28 VDC
Current consumption max. (no load):
100 mA
Voltage drop Vd:
<5 VDC
Output function:
Light / dark operate
Output circuit:
PNP
Output current:
20 mA
Short circuit protection:
Yes
Reverse polarity protection:
Yes, Vs to GND
Width / diameter:
20.6 mm
Height / length:
65 mm
Depth:
50 mm
Design:
Rectangular
Housing material:
Die-cast zinc
Front (optics):
Glass
Connection types:
Connector M12 5 pin
Protection class:
IP 67
Operating temperature:
0 … +50 °C
Datasheet:
View
