The Baumer OXE7.E15T-L82A.SIMD.7AI 11177353 is a high-precision optical sensor designed for measuring edges, center, width, and gaps of objects, particularly effective with dark materials. It features a measuring range of 48 to 72 mm in width and 100 to 150 mm in distance, with a high measuring frequency of 111 to 370 Hz. The sensor offers a resolution of 20 µm and repeat accuracy of ±10 µm. It can detect object widths as small as 0.7 mm, gaps of 1.5 mm, and steps of 0.7 mm. The linearity error ranges from ±50 to 75 µm, and it has a low temperature drift of less than 0.03% per Kelvin. The device includes a pulsed red laser diode light source with a wavelength of 656 nm and is classified as Laser class 1. It features a touch display and RS485 for adjustments, and operates within a voltage supply range of 15 to 28 VDC. The sensor is housed in a durable aluminum casing with glass optics, measures 26 x 74 x 55 mm, and weighs 130 g. It is designed to withstand harsh environments with an IP 67 protection class, operating temperatures from -20 to +50 °C, and high resistance to vibration and shock. Outputs include analog and RS 485 signals, with additional features like LED indicators for power and output status, and comprehensive protection against reverse polarity and short circuits.
- Type:
- Measuring mode: edges, center, width, gap
- Version:
- PosCon OXE7 - for very precise measurements and dark objects
- Measuring range (width):
- 48 72 mm
- Measuring range (distance):
- 100 150 mm
- Measuring frequency:
- 111 370 Hz
- Resolution:
- 20 µm
- Repeat accuracy:
- ± 10 µm
- Smallest detectable object width:
- 0.7 mm
- Smallest detectable gap:
- 1.5 mm
- Smallest detectable step:
- 0.7 mm
- Linearity error:
- ± 50 75 µm
- Temperature drift:
- < 0,03 % measured value/K
- Power on indication:
- LED green
- Output indicator:
- LED yellow / LED red
- Light source:
- Pulsed red laser diode
- Wave length:
- 656 nm
- Laser class:
- 1
- Optical peak power max.:
- 15 mW
- Adjustment:
- Touch Display, RS485
- Response time / release time:
- 8.1 18 ms
- Voltage supply range +Vs:
- 15 28 VDC
- Current consumption max. (no load):
- 150 mA
- Output circuit:
- Analog and RS 485
- Output signal:
- 4 ... 20 mA / 0 ... 10 VDC
- Switching output:
- Push-pull
- Output function:
- Out 1 / Alarm
- Output current:
- 100 mA
- Baud rate:
- 115200, adjustable
- Reverse polarity protection:
- Yes, Vs to GND
- Short circuit protection:
- Yes
- Width / diameter:
- 26 mm
- Height / length:
- 74 mm
- Depth:
- 55 mm
- Design:
- Rectangular, front view
- Housing material:
- Aluminum
- Front (optics):
- Glass
- Connection types:
- Connector M12 8 pin
- Weight:
- 130 g
- Ambient light immunity:
- < 35 kLux
- Operating temperature:
- -20 +50 °C
- Protection class:
- IP 67
- Storage temperature:
- -25 +75 °C
- Vibration (sinusoidal):
- IEC 60068-2-6:2008 1.5 mm p-p at f = 10 - 57 Hz, 10 cycles per axis 10 g at f = 58 - 2000 Hz, 10 cycles per axis
- Shock (semi-sinusoidal):
- IEC 60068-2-27:2009 50 g / 11 ms resp. 100 g / 6 ms, 10 jolts per axis and direction 100 g / 2 ms, 5000 jolts per axis and direction
