Baumer PA213.009AX01

Baumer PA213.009AX01

Baumer
SKU:
11041704
Availability:
Contact us to confirm availability and lead times.
$161.64
Condition:
New
Current Stock:
Description
The Baumer PA213.009AX01 is a high-performance sensor designed for precision measurement applications. It features advanced technology for reliable and accurate data collection. For detailed specifications and features, you can view the datasheet [here](https://www.baumer.com/medias/__secure__/Baumer_PA213.009AX01_EN_20240814_DS.pdf?mediaPK=9193003122718).
Additional Information
Type:
Retro-reflective sensor
Light source:
Pulsed red LED
Actual range Sb:
5.5 m
Nominal range Sn:
6.8 m
Polarization filter:
Yes
Alignment / soiled lens indicator:
Flashing light indicator
Light indicator:
LED yellow
Sensitivity adjustment:
Potentiometer, 270°
Wave length:
660 nm
Suppression of reciprocal influence:
Yes
Response time / release time:
< 0.5 ms
Voltage supply range +Vs:
10 … 30 VDC
Current consumption max. (no load):
25 mA
Current consumption typ.:
22 mA
Voltage drop Vd:
<1.8 VDC
Output function:
Light / dark operate
Output circuit:
PNP
Output current:
100 mA
Short circuit protection:
Yes
Reverse polarity protection:
Yes
Width / diameter:
20 mm
Height / length:
42 mm
Depth:
15 mm
Design:
Rectangular
Housing material:
Plastic (PBT-ASA)
Front (optics):
PMMA
Connection types:
Connector M8 4 pin
Operating temperature:
-25 … +65 °C
Protection class:
IP 67
Datasheet:
View
