Baumer U500.TB0.2-ZZZZ.72F 11200636 is an ultrasonic sensor designed as an emitter with a scanning range of 0 to 2000 mm and operates at a sonic frequency of 200 kHz. It features a green LED power indication and is powered by a 12 to 30 VDC supply, consuming a typical current of 25 mA. The sensor includes short circuit and reverse polarity protection, ensuring reliability and safety in operation. Housed in a rectangular, plastic body (ASA, PMMA) with a PEEK-coated active face, it measures 18 mm in width, 45 mm in length, and 32 mm in depth. The sensor connects via an M12 5-pin connector and operates within a temperature range of -25 to +65 °C, with a storage temperature range of -40 to +75 °C. It is rated IP 67 for protection against dust and water ingress, making it suitable for a variety of industrial applications.
- Emitter / receiver:
- Emitter
- Scanning range Sd:
- 0 2000 mm
- Scanning range far limit Sde:
- 0 2000 mm
- Sonic frequency:
- 200 kHz
- Power on indication:
- LED green
- Voltage supply range +Vs:
- 12 30 VDC
- Current consumption typ.:
- 25 mA
- Residual ripple:
- < 10 % Vs
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes, Vs to GND
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Coating active face:
- PEEK
- Width / diameter:
- 18 mm
- Height / length:
- 45 mm
- Depth:
- 32 mm
- Connection types:
- Connector M12 5 pin
- Operating temperature:
- -25 +65 °C
- Storage temperature:
- -40 +75 °C
- Protection class:
- IP 67
