The Baumer UR18.TB0.2-ZZZZ.9SF 11200648 is an ultrasonic sensor designed for precise distance measurement within a range of 0 to 2000 mm. It operates at a sonic frequency of 200 kHz and features a green LED power indication. This sensor is equipped with a 12 to 30 VDC voltage supply range and has a typical current consumption of 25 mA. It includes safety features such as short circuit and reverse polarity protection. The cylindrical threaded design, made from stainless steel (V2A) and TR90 with a PEEK-coated active face, measures 18 mm in width and 64 mm in length. It connects via an M12 5-pin connector and is suitable for operating temperatures between -25 to +65 °C. The sensor is highly durable, boasting an IP 69 protection class for the housing and IP 67 for the connection, ensuring reliability in various environmental conditions.
- Emitter / receiver:
- Emitter
- Scanning range Sd:
- 0 2000 mm
- Scanning range far limit Sde:
- 0 2000 mm
- Sonic frequency:
- 200 kHz
- Power on indication:
- LED green
- Voltage supply range +Vs:
- 12 30 VDC
- Current consumption typ.:
- 25 mA
- Residual ripple:
- < 10 % Vs
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes, Vs to GND
- Design:
- Cylindrical threaded
- Housing material:
- Stainless steel (V2A) / TR90
- Coating active face:
- PEEK
- Width / diameter:
- 18 mm
- Height / length:
- 64 mm
- Connection types:
- Connector M12 5 pin
- Operating temperature:
- -25 +65 °C
- Storage temperature:
- -40 +75 °C
- Protection class:
- IP 69
- Protection class (connection):
- IP 67
- Datasheet:
- View
