Datasensing AM1/AP-4A8R Sensors

The Datasensing AM1/AP-4A8R Sensor is an advanced inductive sensor designed for precision and reliability. Featuring an M12 unshielded design, this sensor operates with a nominal sensing distance of 8mm and an operating distance of 0 to 6.48mm. It is optimized for a standard target size of 24x24mm FE360, with correction factors for various materials including copper (0.41), aluminium (0.46), brass (0.52), and stainless steel (0.71). The sensor ensures minimal thermal drift of Sr (<10%) and repeat accuracy of less than 5% at 24V and 23°C ±5°C. With a hysteresis range of 1 to 20%, this proximity sensor features a PNP output type with a normally open (NO) function, capable of switching frequencies up to 2kHz. It operates within a voltage range of 10 to 30Vdc, with a no-load supply current of ?10mA and a load current of ?200mA. The output voltage drop is maintained at ?1.8V at 200mA, with a maximum ripple content of ?10%. The sensor is equipped with a yellow LED indicator for output state, and includes essential protections such as short-circuit, reverse polarity, impulsive overvoltage, and protection against inductive loads. Constructed with a nickel-plated brass housing and PBT active head material, it is designed for durability and reliability, with an IP67 mechanical protection rating. The sensor is supplied with a 10m PVC cable and two M12x1 nuts for easy installation. It is CE and UR approved, with EMC compatibility per IEC 60947-5-2 standards, and is resistant to shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27 standards. Operating efficiently in temperatures ranging from -25°C to +70°C, the Datasensing AM1/AP-4A8R Sensor is an ideal choice for various industrial applications.
