Datasensing AM1/CN-1A Sensors

The Datasensing AM1/CN-1A Sensors are high-performance inductive sensors designed for precision and reliability. Featuring a nominal sensing distance of 2mm and an operating distance of 0 to 1.62mm, these sensors are ideal for detecting standard targets of 12x12mm FE360. With a robust nickel-plated brass housing and a shielded M12 standard flush mount, they ensure durability and protection in demanding environments. These sensors offer a wide range of models, including standard, short body, and long distance, with options for 2 or 3 wire configurations. The output is facilitated through a 2m PVC cable, with M12 and M8 plug cable exits available. The AM1/CN-1A sensors are equipped with NPN output type and NC output function, supporting a switching frequency of 2kHz and operating voltage between 10 to 30Vdc. Engineered for safety and efficiency, they include features such as short-circuit protection, reverse polarity protection, and impulsive overvoltage protection. The sensors are also equipped with a yellow LED indicator for output state, ensuring easy monitoring. With a high degree of protection (IP67) and compliance with EMC compatibility standards (IEC 60947-5-2), these sensors are built to withstand shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27 standards. The AM1/CN-1A sensors are suitable for a wide range of industrial applications, offering reliable performance even in extreme temperatures ranging from -25°C to +70°C. Supplied with two M12x1 nuts for easy installation, these sensors are CE and UR approved, making them a trusted choice for professionals seeking quality and precision in proximity sensing.
