Datasensing AM6/AP-1AAN Sensors

The Datasensing AM6/AP-1AAN Sensors are designed for high-performance proximity detection in industrial environments. Featuring an M12 short case flush mount, these inductive sensors offer a nominal sensing distance of 2mm and an operating range of 0 to 1.62mm. They are equipped with a PNP output type and a normally open (NO) output function, ensuring reliable operation with a switching frequency of up to 2kHz. The sensors operate within a voltage range of 10 to 30Vdc, with a no-load supply current of ? 10mA and a load current of ? 200mA. Constructed with a nickel-plated brass housing and a PBT active head, these sensors are built to withstand harsh conditions, offering mechanical protection rated at IP67. They are also equipped with short-circuit, reverse polarity, and impulsive overvoltage protection, making them robust and durable. The sensors feature a yellow LED indicator for output state and have a time delay before availability of ? 50ms. With a thermal drift of Sr of less than 10% and a repeat accuracy of less than 5% at 24V and 23°C ±5°C, these sensors provide precise and consistent performance. They are compatible with standard targets of 12x12mm FE360 and have correction factors for various materials, including copper (0.22), aluminium (0.31), brass (0.41), and stainless steel (0.77). The sensors are approved with CE and UR certifications and comply with EMC compatibility standards IEC 60947-5-2. They are also tested for shocks and vibrations according to IEC 60068-2-6 and IEC 60068-2-27 standards. Supplied with two M12x1 nuts, these sensors are easy to install and integrate into existing systems. Operating efficiently in temperatures ranging from -25°C to +70°C, the Datasensing AM6/AP-1AAN Sensors are ideal for a wide range of industrial applications.
