The Datasensing AM6/BP-3H Sensors are high-performance inductive sensors designed for precision and reliability in various industrial applications. Featuring a compact M12 short shielded design, these sensors offer both Normally Open (NO) and Normally Closed (NC) PNP output functions, making them versatile for different operational needs. With a nominal sensing distance of 4mm and an operating range of 0 to 3.2mm, they are ideal for detecting standard targets of 12x12mm FE360. The sensors are equipped with advanced features such as short-circuit, reverse polarity, and impulsive overvoltage protection, ensuring durability and safety in demanding environments.
The AM6/BP-3H model supports a wide range of models, including standard, short body, and long distance, with options for cable, M12, and M8 plug cable exits. It is compatible with 2 and 3 wire configurations, and ATEX models are available upon request for hazardous locations. The sensor's robust construction includes a nickel-plated brass housing and PBT active head material, providing IP67 mechanical protection against dust and water ingress.
With a switching frequency of 2kHz and an operating voltage range of 10 to 30Vdc, these sensors deliver fast and efficient performance. The yellow LED indicator provides a clear output state, while the low no-load supply current of ? 10mA and load current of ? 200mA ensure energy efficiency. The AM6/BP-3H sensors are CE and UR approved, with EMC compatibility per IEC 60947-5-2 standards, and are designed to withstand shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27 standards. Supplied with two M12x1 nuts, these sensors are easy to install and maintain, making them a reliable choice for proximity sensing applications.
- Nominal sensing distance:
- 4mm
- Operanting distance:
- 0 3,2mm
- Standard target:
- 12x12mm FE360
- Correction Factor:
- copper: 0,33 / aluminium: 0,4 / brass: 0,5 / stainless steel: 1,05
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M12 short case flush mount
- Functions:
- Proximity
- Output type:
- PNP
- Output Function:
- NO + NC
- Switching frequency:
- 2kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Shielded
- Weight:
- 20g
- Housing Material:
- Nickel-plated brass
- Connections:
- M12 plug
- Active Head Material:
- PBT
- Tightening torque:
- 10Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M12
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M12x1
- Mechanical Protection:
- IP67
