Datasensing AM6/CN-1H Sensors

The Datasensing AM6/CN-1H Sensors are high-performance inductive sensors designed for precision and reliability in various industrial applications. Featuring a compact M12 short shielded design, these sensors offer a nominal sensing distance of 2mm and an operating distance of 0 to 1.62mm, making them ideal for close-range detection tasks. The sensors are equipped with an NPN output type and a normally closed (NC) output function, ensuring efficient signal processing with a switching frequency of 2kHz. Constructed with a robust nickel-plated brass housing and an active head made of PBT, the AM6/CN-1H sensors are built to withstand harsh environments, with an operating temperature range of -25°C to +70°C and a degree of protection rated at IP67. The sensors are designed to handle a load current of up to 200mA, with a low no-load supply current of ? 10mA and a minimal output voltage drop of ? 1.8V at 200mA. For enhanced safety and durability, these sensors come with built-in short-circuit protection, reverse polarity protection, impulsive overvoltage protection, and protection against inductive loads. The yellow LED indicator provides a clear visual indication of the output state, while the sensors' EMC compatibility with IEC 60947-5-2 ensures reliable performance in electromagnetic environments. The AM6/CN-1H sensors are easy to install with their M12 plug connections and come with two M12x1 nuts for secure mounting. With a weight of just 20g and a tightening torque of 10Nm, these sensors are both lightweight and sturdy. Additionally, they are approved by CE and UR, ensuring compliance with international safety standards. Whether you need standard, short body, or long-distance models, the Datasensing AM6/CN-1H Sensors provide versatile solutions for your proximity sensing needs.
