Datasensing AT1/AN-3AVE80 Sensors

The Datasensing AT1/AN-3AVE80 Inductive Sensor is a robust and reliable solution for proximity detection needs. Designed with an M30 shielded housing, this sensor features a NO/NPN output type and is equipped with a 200mm axial cable and M12 plug for easy connectivity. It offers a nominal sensing distance of 15mm and operates effectively within a range of 0 to 12.1mm, making it suitable for various industrial applications. The sensor is optimized for standard targets of 45x45mm FE360, with correction factors for different materials such as copper, aluminum, brass, and stainless steel. Engineered for precision, it boasts a thermal drift of Sr under 10% and a repeat accuracy of less than 5% at 24V and 23°C. The sensor's hysteresis ranges from 1 to 20%, ensuring consistent performance. It operates at a switching frequency of 200Hz and supports an operating voltage between 10 to 30Vdc. With a no-load supply current of ? 20mA and a load current capacity of ? 400mA, it is energy-efficient and reliable. The sensor is designed with safety in mind, featuring short-circuit, reverse polarity, and impulsive overvoltage protection, as well as protection against inductive loads. Its nickel-plated brass housing and PBT active head material ensure durability, while the IP67 mechanical protection rating guarantees resilience in harsh environments. The sensor is CE and UR approved, with EMC compatibility per IEC 60947-5-2 standards. It also includes two M30x1.5 nuts for secure mounting and can withstand operating temperatures from -25°C to +70°C.
