Connector Female M8 Axial 4 poles cable PUR 5 m
- Nominal current:
- 4 A
- Led:
- no
- Wires:
- 4
- Rated impulse voltage:
- 1,5 kV
- Nominal voltage:
- Max. 60 V ac/dc
- Connections:
- With open ended wires
- Tightening torque:
- 0,4 Nm
- Fibre lengh (m):
- 5
- Head type:
- Axial
- Plug:
- M8
- Outer diameter:
- Ø 4,7 mm ± 0,2mm
- Jacket material:
- PUR
- Wire isolation:
- PVC
- Conductors section:
- 0,25 mm2(32 x 0,10 mm2)
- Degree of protection:
- IP67
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
