Datasensing FAI7/BP-1AAN Sensors
Datasensing
$127.40
The Datasensing FAI7/BP-1AAN Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a diffuse reflection function with a nominal sensing distance of 400mm, these sensors are ideal for medium-distance applications. The M18 sensors operate on a 10...30 VDC power supply and are equipped with both axial and radial optics, ensuring versatile installation options.
With a robust IP67 protection rating, these sensors are built to withstand harsh environments, offering total protection against electric damages. The metallic or plastic housing options provide durability, while the sensitivity adjustment trimmer allows for fine-tuning to suit specific needs. The sensors are capable of detecting transparent objects with retro-reflective models and red emission, making them suitable for a variety of industrial applications.
The FAI7/BP-1AAN Sensors feature a PNP NO+NC output type, with a switching frequency of 250Hz and a response time of just 2ms, ensuring quick and accurate performance. The sensors are equipped with LED indicators for easy status monitoring and offer comprehensive protection features, including short-circuit, overvoltage, and reverse polarity protection.
Designed to operate in temperatures ranging from -25°C to +70°C, these sensors are suitable for a wide range of environments. They are CE and cULus listed, ensuring compliance with international standards. The sensors come with a 2m PVC cable for easy connectivity and are supplied with nuts and a screwdriver for convenient installation. With their high reliability and precision, the Datasensing FAI7/BP-1AAN Sensors are an excellent choice for industrial automation and control applications.
- Nominal sensing distance:
- 400mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Notes:
- white target Kodak 90% 200 x 200mm
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 130g
- Housing Material:
- Nickel plated brass / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus Ex: II 3G Ex nA IIC T6 Gc II 3D Ex tc IIIB T85°C Dc
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
