Datasensing FAI8/BP-0E6X Sensors
Datasensing
$135.21
The Datasensing FAI8/BP-0E6X Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring an M18 axial diffuse design, these sensors offer a nominal sensing distance of 1.5 meters, with a sensitivity adjustment trimmer for fine-tuning. They operate on a 10 to 30 VDC power supply and are equipped with PNP NO+NC output functions, ensuring versatile application compatibility. The sensors boast a robust IP67 protection rating, safeguarding against dust and water ingress, and are housed in durable PBT/PC materials with a metallic or plastic option. With a high switching frequency of 250Hz and a rapid response time of 2ms, these sensors are ideal for fast-paced environments. They are equipped with LED indicators for easy status monitoring and offer comprehensive protection features, including short-circuit, overvoltage, and reverse polarity protection. The FAI8/BP-0E6X Sensors are CE and cULus approved, ensuring compliance with international standards, and come with supplied accessories such as M18 nuts and a screwdriver for convenient installation.
- Nominal sensing distance:
- 1,5m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
