Datasensing FAIH/X0-2A Sensors
Datasensing
$72.50
The Datasensing FAIH/X0-2A Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a 90° radial optic emitter, these sensors offer a nominal sensing distance of 15 meters, making them ideal for a variety of industrial applications. The robust design includes a complete range of M18 sensors with a 10...30 Vdc power supply, ensuring compatibility with various systems.
These sensors are equipped with retro-reflective models for detecting transparent objects, utilizing a red emission and providing an IP67 protection degree for enhanced durability. The housing is available in both metallic and plastic options, catering to different environmental needs. Although sensitivity adjustment is not available, the sensors boast a repeat accuracy of 5% and a thermal drift of Sr ?10% Sr, ensuring consistent performance.
The FAIH/X0-2A Sensors are designed with total protection against electric damages, including reverse polarity protection and impulsive voltage resistance. They feature a switching frequency of 250Hz and a response time of just 2ms, making them highly responsive. The sensors are equipped with LED indicators for power status and have a no-load supply current of ? 25mA.
With a compact design of M18 x 1/L=78.5mm and a weight of 50g, these sensors are easy to install and integrate into existing systems. The operating temperature range of -25°C to +70°C ensures reliable performance in various environments. The sensors are CE and cULus listed, meeting international standards for safety and quality.
Supplied with M18 x 1 nuts for secure installation, the Datasensing FAIH/X0-2A Sensors are a reliable choice for industries requiring precise and durable sensing solutions.
- Nominal sensing distance:
- 15m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter with check
- Emitter/Receiver:
- Emitter
- Check Input:
- BK/2 connected to 0Vdc swithing off the emission
- Optic position:
- Radial 90°
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (powerON)
- Time delay before availability:
- ?200ms
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Weight:
- 50g
- Housing Material:
- PBT/ PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
