Datasensing FAR2/BP-2A Sensors
Datasensing
$80.77
The Datasensing FAR2/BP-2A Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a 90° diffuse reflection function, these sensors offer a nominal sensing distance of 100mm, making them ideal for short-distance applications. With a robust PNP NO+NC output type, they ensure seamless integration into various systems. The sensors are equipped with a 2m axial plastic cable for easy installation and connectivity.
Built to withstand challenging environments, the FAR2/BP-2A sensors boast an IP67 protection degree, ensuring total protection against dust and water ingress. The durable housing, available in metallic or plastic, provides excellent resistance to mechanical stress. These sensors are designed to operate efficiently within a wide voltage range of 10
30VDC, with a low no-load supply current of ? 30mA and a load current capacity of ?100mA.
The sensors feature a high switching frequency of 250Hz and a rapid response time of 2ms, ensuring quick and accurate detection. They are equipped with LED indicators for easy status monitoring and offer comprehensive protection against short circuits, overvoltage, and reverse polarity. The sensors are also designed to resist interference from external light sources, withstanding up to 5000lux from incandescent lamps and 10000lux from sunlight.
With approvals from CE and cULus, the Datasensing FAR2/BP-2A Sensors meet stringent safety and performance standards. They are engineered to operate in temperatures ranging from -25°C to +70°C, making them suitable for a variety of industrial applications. The sensors come with supplied accessories, including M18 x 1 nuts, for secure mounting and installation.
- Nominal sensing distance:
- 100mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Radial 90°
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 50g
- Housing Material:
- PBT/ PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
