The Datasensing FC8U/0P-M307-1F Sensors are designed for precise label detection with a 3mm width and 69mm depth slot. Utilizing advanced ultrasonic technology, these sensors are ideal for detecting transparent labels and any opaque materials. The compact size and aluminum casing make them easy to install in various environments. Featuring both NPN and PNP output types, the sensors offer LO/DO total configurability. With a maximum switching frequency of 1,500 Hz, they ensure rapid and accurate detection. The sensors operate on a voltage range of 12 - 24Vdc and have a no-load supply current of ? 45mA. They are equipped with short-circuit and reverse polarity protection, ensuring reliable performance. The M8 4-pole connector facilitates easy integration, while the IP65 rating guarantees durability in challenging conditions. Suitable for operating temperatures between +5°C and +55°C, these sensors are CE and UL approved, ensuring compliance with international standards.
- Nominal sensing distance:
- 3mm
- minimum detectable object:
- 2mm
- Si:
- Yes
- Sensitivity adjustment:
- Yes
- +/-50 µm a 150m/min:
- +/-20 µm at 120m/min
- 200 m/min:
- 180 m/min
- 2mm:
- 2mm
- Output type:
- PNP
- Output Function:
- LO/DO selectable
- Switching frequency:
- 1.500Hz
- Operating Voltage:
- 12 - 24Vdc
- No-Load supply current:
- ? 45mA
- Load current:
- 100mA
- Output voltage drop:
- ? 2 V @ IL =100 mA
- Max ripple content:
- ? 10%
- Time delay before availability:
- 300ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- Ultrasonic
- Weight:
- 160g
- Housing Material:
- Painted aluminum
- Connections:
- M8 plug 4 pin
- Storage temperature:
- - 20°C + 70°C
- Width slot detection:
- 3mm
- Depth slot detection:
- 69mm
- Approvals:
- CE UL
- EMC compatibility:
- EN 60529
- Degree of protection:
- IP65
- Mechanical Protection:
- IP65
