The Datasensing FFIH/00-1EV5 is a robust photoelectric sensor designed for precision and reliability. Featuring an axial emitter with a nominal sensing distance of 20 meters, this sensor is housed in a smooth, stainless steel AISI 316L casing with a PA12 plug, ensuring durability and resistance to harsh environments. It operates on a voltage range of 10 to 30VDC, with a no-load supply current of ? 40mA and a maximum ripple content of ?10%. The sensor is equipped with LED indicators for green stability and yellow output state, providing clear operational status. It includes essential protections such as short-circuit and reverse polarity protection, and it emits LED infrared light at 880nm. The M12 plug connection and Ø 17.5mm dimension make it easy to integrate into various systems. With approvals from CE, cULus, and ECOLAB Diversey, and EMC compatibility with EN 60947-5-2, this sensor is suitable for a wide range of industrial applications. It operates efficiently in temperatures ranging from -25°C to +80°C and offers mechanical protection rated at IP68 and IP69K, ensuring performance in demanding conditions.
- Nominal sensing distance:
- 20m
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter
- Emitter/Receiver:
- Emitter
- Optic position:
- Axial
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 40mA
- Max ripple content:
- ?10%
- LED indicators:
- Green Stability
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Housing Material:
- Stainless steel AISI 316L / PA12 plug
- Connections:
- M12 plug
- Active Head Material:
- PA12
- Diameter/Dimension:
- Ø 17,5mm
- Approvals:
- CE cULus ECOLAB Diversey
- EMC compatibility:
- EN 60947-5-2
- Dimensions:
- 17,5/L=83mm
- Operating Temperature:
- - 25°C + 80°C (Without freeze)
- Mechanical Protection:
- IP68, IP69K
