The Datasensing FQIH/00-0E Sensors are advanced photoelectric sensors designed for precision and reliability in various industrial applications. Featuring an axial emitter with a nominal sensing distance of 20 meters, these sensors are equipped with a robust plastic housing and an M12 connector for easy installation. The FQIH/00-0E model offers a wide range of configurations, including direct diffuse, retro-reflective, polarized, and fixed-focus options, catering to diverse sensing needs.
Engineered for durability, the sensors boast a nickel brass or plastic housing with an IP67 protection degree, ensuring complete protection against electrical damages and harsh environmental conditions. The sensors are CE approved and comply with EMC compatibility standards (EN 60947-5-2), making them suitable for global use.
With a repeat accuracy of 5% and a thermal drift of ?10% Sr, these sensors deliver consistent performance. They operate on a voltage range of 10 to 30VDC, with a no-load supply current of ?25mA and a maximum ripple content of ?10%. The LED indicators provide a clear visual status with a yellow light indicating power ON.
The FQIH/00-0E sensors are designed for ease of use, featuring a compact size with dimensions of M18 x 1 /L =66.3mm and a lightweight design at 30g. The active head is made of durable PC material, and the sensors come with supplied accessories, including M18 x 1 nuts and a screwdriver for convenient setup. With a tightening torque of 1Nm and an operating temperature range of -25°C to +70°C, these sensors are built to withstand challenging conditions without freezing.
Ideal for applications requiring reliable sensing solutions, the Datasensing FQIH/00-0E Sensors offer exceptional performance and versatility, making them a valuable addition to any industrial setup.
- Nominal sensing distance:
- 20m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter
- Emitter/Receiver:
- Emitter
- Optic position:
- Axial
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (powerON)
- Time delay before availability:
- ?200ms
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
