Datasensing MPR/00-1E Sensors
Datasensing
$161.69
The Datasensing MPR/00-1E Sensors are advanced photoelectric sensors designed for precise detection tasks. Featuring a right-angle M18 receiver, these sensors offer a nominal sensing distance of 16 meters and are equipped with a metal M12 connector for robust connectivity. The sensors support both NPN and PNP output types, with selectable NO/NC output functions, ensuring versatile integration into various systems. With a high switching frequency of 30Hz and a rapid response time of 16.66ms, they are ideal for fast-paced environments.
These sensors boast a wide range of models, including diffuse, retro-reflective, polarized, through-beam detection, and background suppression, catering to diverse application needs. The through-beam models provide an extended sensing range, while retro-reflective models utilize red visible polarized light for enhanced accuracy. The right-angle optic design (MP) and fixed distance background suppression models further expand their usability.
Built to withstand challenging conditions, the MPR/00-1E Sensors offer complete protection against electrical damage, including short-circuit and overvoltage protection. They are resistant to external light interference, withstanding up to 3000 lux from incandescent lamps and 10000 lux from sunlight. The sensors are housed in durable nickel-plated brass with a PC plug, ensuring longevity and reliability. With an IP67 degree of protection, they are suitable for use in harsh environments.
Additional features include LED indicators for status output, a time delay before availability of ?200ms, and a mechanical protection rating of IP67. The sensors are compliant with CE and cURus approvals and meet EMC compatibility standards (EN 60947-5-2). They are also designed to endure shocks and vibrations as per IEC standards, making them a robust choice for industrial applications. Supplied with M18 x 1 nuts, these sensors are ready for immediate installation and operation.
- Nominal sensing distance:
- 16m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Radial 90°
- Output type:
- Decout NPN/PNP Selectable NO/NC Selectable
- Output Function:
- NO/NC Selectable
- Switching frequency:
- 30Hz
- Response time:
- 16,66ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Impulsive Overvoltage Protection
- Weight:
- 100g
- Housing Material:
- Nickel plated brass / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- 25°C..+ 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
