Datasensing MVP/C0-0A Sensors
Datasensing
$123.61
The Datasensing MVP/C0-0A Sensors are advanced photoelectric sensors designed for precision and reliability in various industrial applications. Featuring a polarized function principle, these sensors offer a nominal sensing distance of 3.5 meters, ensuring accurate detection with minimal thermal drift of ?10%Sr and a repeat accuracy of 5%. The sensors are equipped with a robust M12 plug cable exit available in both axial and right-angle shapes, providing flexibility in installation.
Engineered for durability, the MVP/C0-0A Sensors boast an IP67 protection degree, safeguarding against electrical damage and environmental factors. The sensors operate efficiently within a wide voltage range of 20 to 253VAC at 50-60Hz, with a low no-load supply current of ?30mARMS and a load current capacity of 5 to 300mARMS. The output type is TRIAC NC, with a switching frequency of 25Hz and a response time of 20ms, ensuring swift and reliable performance.
Constructed with high-quality materials, including a PBT/PC housing and PMMA active head, these sensors are built to withstand harsh conditions, with an operating temperature range of -25°C to +70°C. The sensors are also equipped with red LED indicators for status output, and they are resistant to interference from external light sources up to 10,000 lux.
With CE and cURus approvals, as well as EMC compatibility with EN 60947-5-2 standards, the Datasensing MVP/C0-0A Sensors are a dependable choice for applications requiring high sensing range and complete protection against shocks and vibrations. Supplied with M18 x 1 nuts for easy installation, these sensors are an ideal solution for enhancing operational efficiency and safety in demanding environments.
- Nominal sensing distance:
- 3,5m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- TRIAC NC
- Output Function:
- NC
- Switching frequency:
- 25Hz
- Response time:
- 20ms
- Operating Voltage:
- 20...253VAC/50-60Hz
- No-Load supply current:
- ? 30mARMS
- Load current:
- 5 300mARMS
- Leakage current:
- 6A
- Output voltage drop:
- ?3V@Iload=300mARMS
- Max ripple content:
- ?10%
- LED indicators:
- Red (status output)
- Time delay before availability:
- ?200ms
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 100g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 60° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cURus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
