Datasensing QMR8/0P-0AVF80 Sensors

The Datasensing QMR8/0P-0AVF80 Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a miniature cubic design, these sensors utilize a diffuse reflection principle for long-distance detection, with a nominal sensing distance of 1 meter. The sensors are equipped with a trimmer for sensitivity adjustment, ensuring optimal performance with a repeat accuracy of 5%. The QMR8/0P-0AVF80 model offers a PNP output type with selectable light/dark operation, and a high switching frequency of 1kHz, providing a rapid response time of 500µs. Designed to operate within a voltage range of 10 to 30VDC, these sensors maintain a low no-load supply current of ?30mA and a load current of ?100mA. Built to withstand challenging environments, the sensors feature a robust PA66 housing with IP67 mechanical protection, ensuring durability against dust and water ingress. The active head is made from PMMA, and the unit is equipped with short-circuit and reverse polarity protection for enhanced safety. The sensors are fitted with a 200mm PVC cable and an M8 3-pin plug for easy connectivity. LED indicators provide clear status and stability feedback, with a yellow LED for output status and a green LED for stability. The sensors are designed to resist interference from external light sources, with a tolerance of up to 3000lux from incandescent lamps and 10000lux from sunlight. With approvals from CE and EMC compatibility with EN 60947-5-2, these sensors are suitable for a wide range of industrial applications. They are capable of operating in temperatures ranging from -25°C to +70°C, with storage temperatures between -30°C and +80°C. The compact dimensions of 31.2x21x13mm make them ideal for installations where space is limited.
