Datasensing QMRL/0N-0A Sensors
Datasensing
$152.08
The Datasensing QMRL/0N-0A Sensors are advanced miniature cubic photoelectric sensors designed for high-performance detection of transparent objects. With a nominal sensing distance of 4 meters and a thermal drift of Sr ?10%, these sensors ensure precise and reliable operation. The sensors feature a 2 kHz switching frequency and background suppression with mechanical adjustment, making them suitable for a wide range of applications.
Equipped with a trimmer for sensitivity adjustment, the QMRL/0N-0A offers a minimum sensing distance of 0.4 meters, ensuring accurate detection even in close proximity. The NPN L/D selectable output type provides flexibility in output function, while the robust design includes complete protection against electrical damages, short-circuit protection, and reverse polarity protection.
The sensors are housed in a durable PA66 material with an IP67 degree of protection, ensuring resilience in harsh environments. The compact dimensions of 31.2x21x13mm and a weight of 52g make them easy to integrate into various systems. Operating efficiently within a voltage range of 10
30VDC, they consume a no-load supply current of ? 30mA and support a load current of ?100mA.
With LED indicators for status output and stability, the QMRL/0N-0A sensors provide clear visual feedback. They are designed to withstand external light interference up to 3000lux from incandescent lamps and 10000lux from sunlight. The sensors are CE cULus approved and EMC compatible with EN 60947-5-2 standards, ensuring compliance with industry regulations.
- Nominal sensing distance:
- 4m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Minimum sensing distance (blind zone):
- 0,4m
- Function Principle:
- Transparent objects
- Notes:
- On RL110 reflector
- Optic position:
- Radial 90°
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output), green (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (630nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 52g
- Housing Material:
- PA66
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Storage temperature:
- - 30°C + 80° C (Without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
