Datasensing QMRS/0P-0AVF80 Sensors

The Datasensing QMRS/0P-0AVF80 Sensors are designed for precision and reliability in various industrial applications. Featuring a miniature cubic design, these photoelectric sensors offer background suppression with a nominal sensing distance of 200mm, ensuring accurate detection even in challenging environments. The sensor's sensitivity can be easily adjusted using a trimmer, and it boasts a repeat accuracy of 5%. With a minimum sensing distance of 30mm, it is ideal for close-range applications. The sensor operates on a PNP L/D selectable output type, with a switching frequency of 1kHz and a rapid response time of 500µs. It functions efficiently within an operating voltage range of 10 to 30VDC, consuming a no-load supply current of ? 30mA. The robust design includes short-circuit and reverse polarity protection, as well as impulsive overvoltage protection, ensuring durability and safety. Constructed with a PA66 housing and a PMMA active head, the sensor is built to withstand harsh conditions, with an IP67 mechanical protection rating. It can operate in temperatures ranging from -25°C to +70°C and is resistant to shocks and vibrations as per IEC standards. The sensor is equipped with a 200mm PVC cable and an M8 plug for easy connectivity, and its compact dimensions of 31.2x21x13mm make it suitable for space-constrained installations. LED indicators provide clear status output, and the sensor is compatible with EMC standard EN 60947-5-2, ensuring reliable performance in environments with external light interference.
