Datasensing QXP/A0-1A Sensors
Datasensing
$196.24
The Datasensing QXP/A0-1A Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a polarized function principle, these sensors offer a nominal sensing distance of 3 meters with repeat accuracy of ? 5%. The axial optic position is complemented by a 2-meter PVC cable, ensuring flexible installation options. Equipped with two LED indicators, the red LED displays output status while the green LED indicates stability, providing clear visual feedback.
These sensors are capable of long-distance detection with a precision beam and fast response time of 666µs, making them ideal for high-speed applications. The NPN/PNP selectable output type allows for versatile integration into various systems, with a high output current capacity of over 300mA. The sensors operate efficiently within a voltage range of 10 to 30VDC, with a no-load supply current of ? 20mA and a load current of ? 300mA.
Built to withstand challenging environments, the QXP/A0-1A Sensors feature a robust ABS housing with an IP65 degree of protection, ensuring durability against dust and water ingress. The sensors are also equipped with short-circuit and reverse polarity protection, enhancing their reliability. With a compact cubic design measuring 15x23x40mm and weighing just 70g, these sensors are easy to install and integrate into existing systems.
The sensors are supplied with ST70 mounting brackets and screws for convenient setup. They are CE approved and comply with EMC compatibility standards EN 60947-5-2, ensuring they meet rigorous safety and performance criteria. Suitable for operating temperatures ranging from -25°C to +70°C, the Datasensing QXP/A0-1A Sensors are a versatile and dependable choice for a wide range of industrial applications.
- Nominal sensing distance:
- 3m
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Polarized
- Optic position:
- Axial
- Output type:
- NPN/PNP Selectable NO
- Output Function:
- NO
- Switching frequency:
- 750Hz
- Response time:
- 666µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Dimensions:
- 15x23x64
- Weight:
- 70g
- Connections:
- 2m PVC cable
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Dimensions:
- 15x23x40
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
