Datasensing RX8/0T-3B37 Sensors
Datasensing
$282.54
The Datasensing RX8/0T-3B37 Sensors are advanced photoelectric sensors designed for versatile applications. Featuring a diffuse reflection model with a nominal sensing distance of 4.5 meters, these sensors are ideal for long-distance detection tasks. The compact design, measuring 26x86.6x61 mm, allows for easy installation in tight spaces, while the robust PC housing ensures durability in various environments.
Equipped with a relay output and multifunctional DECOUT®, the RX8/0T-3B37 offers reliable performance with a switching frequency of 25Hz and a response time of 20ms. The sensor includes a timer function with delay on, delay off, and one-shot capabilities, along with a trimmer for precise sensitivity adjustment. The LED alignment indicator provides 360° visibility, ensuring accurate setup and operation.
The sensor's M12 standard plug cable exit and axial optic position enhance connectivity and flexibility. It operates efficiently within a voltage range of 20...60VDC / 20...253VAC/50-60Hz, with a load current capacity of 3A-250Vac/3A-30Vdc. The RX8/0T-3B37 is designed to withstand harsh conditions, with an operating temperature range of -25°C to +70°C and IP65 mechanical protection.
Additional features include reverse polarity and impulsive overvoltage protection, as well as high resistance to external light interference. The sensor is CE approved and EMC compatible, ensuring compliance with industry standards. Supplied with an ST81 mounting bracket and screws, the Datasensing RX8/0T-3B37 Sensors are a reliable choice for high-performance sensing applications.
- Nominal sensing distance:
- 4,5m
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm EG=1,5
- Optic position:
- Axial
- Output type:
- Relay SPST NO/NC
- Output Function:
- NO/NC
- Switching frequency:
- 25Hz
- Response time:
- 20ms
- Operating Voltage:
- 20...60VDC /20...253VAC/50-60Hz
- No-Load supply current:
- ? 25mARMS
- Load current:
- 3A-250Vac/3A-30Vdc (750VA/90W)
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status) o (alineament), Green (stability)
- Time delay before availability:
- ?200ms
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- ? 5000lux (incandescent lamp)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 90g
- Housing Material:
- PC
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST81 mounting bracket and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
