The Datasensing RXP/0T-1B Sensors are designed for precision and versatility, offering a range of models including diffuse reflection, retro-reflective, polarized, through-beam, and background suppression. These sensors boast high performance with a nominal sensing distance of 6 meters and compact dimensions, making them ideal for various installation scenarios. Equipped with a relay output or multifunctional DECOUT®, they feature a timer function with delay on, delay off, and one-shot capabilities, along with a trimmer for sensitivity adjustment. The sensors include a switch to reduce emission for fine detection in through-beam types and an LED alignment indicator with 360° visibility, ensuring easy setup and operation.
The RXP/0T-1B Sensors are built with robust materials, including a PC housing and PMMA active head, and are designed to withstand harsh environments with an operating temperature range of -25°C to +70°C and IP65 mechanical protection. They are equipped with M12 standard plug cable exits and come with axial and right-angle brackets for flexible mounting options. The sensors offer selectable output types (NPN/PNP and NO/NC) and are protected against short circuits and reverse polarity, ensuring reliable performance. With a high switching frequency of 500Hz and a rapid response time of 1ms, these sensors are perfect for applications requiring quick and accurate detection. Additionally, they are CE and cULus approved, ensuring compliance with international standards.
- Nominal sensing distance:
- 6m
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable Decout NO/NC Selectable
- Output Function:
- Decout NO/NC Selectable
- Switching frequency:
- 500Hz
- Response time:
- 1ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status) o (alineament), Green (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- ? 10000lux (incandescent lamp)
- Weight:
- 90g
- Housing Material:
- PC
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST81 mounting bracket and screws
- Operating Temperature:
- - 25°C + 60°C (Without freeze)
- Mechanical Protection:
- IP65
