Datasensing SAT/0N-1C Sensors
Datasensing
$156.16
The Datasensing SAT/0N-1C Sensors are designed for precision and reliability in various industrial applications. These photoelectric sensors utilize diffuse reflection technology, ideal for short-distance detection up to 200mm. With a nominal sensing distance of 12mm, they ensure accurate performance with a repeat accuracy of 5%. The sensors feature a sensitivity adjustment trimmer, allowing for fine-tuning to suit specific needs.
Equipped with a double LED indicator, these sensors provide clear status updates with green for power ON and yellow for status output. The NPN output type is L/D selectable, offering flexibility in integration. The sensors operate efficiently within a voltage range of 10 to 30VDC, with a low no-load supply current of ?30mA and a load current capacity of ?100mA.
Built to withstand challenging environments, the SAT/0N-1C Sensors boast an IP67 protection rating, ensuring complete protection against dust and water ingress. They are also equipped with short-circuit and reverse polarity protection, enhancing their durability. The robust housing, made from nickel-plated brass with a nylon cable exit, ensures longevity and resistance to mechanical stress.
These sensors are compatible with a wide range of plugs, accessories, and reflectors, making them versatile for various setups. They are approved with CE certification and comply with EMC compatibility standards EN 60947-5-2. With a compact design measuring 21.4mm x 90mm and a weight of 140g, they are easy to install and integrate into existing systems.
Ideal for applications requiring high precision and reliability, the Datasensing SAT/0N-1C Sensors are a dependable choice for industrial automation and control systems.
- Nominal sensing distance:
- 12mm
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green (powerON), Yellow (Status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 140g
- Housing Material:
- Nickel-plated brass / Nylon cable exit
- Connections:
- 2m PVC cable 90°
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
