Datasensing SAT/0P-1K Sensors
Datasensing
$161.40
The Datasensing SAT/0P-1K Sensors are advanced photoelectric sensors designed for precision and reliability in various industrial applications. These sensors feature a diffuse reflection function, ideal for short-distance detection up to 200mm, with a nominal sensing distance of 12mm. Equipped with a sensitivity adjustment trimmer, they offer customizable performance to suit specific needs. The sensors boast a robust construction with a nickel-plated brass housing and a PMMA active head, ensuring durability and resistance to harsh environments.
With a double LED indicator for power and status output, users can easily monitor the sensor's operation. The PNP L/D selectable output function provides flexibility in integration, while the NO/NC selectable output enhances versatility. The SAT/0P-1K Sensors are designed to withstand challenging conditions, featuring IP67 protection against dust and water ingress, as well as comprehensive protection against electrical damage, including short-circuit and reverse polarity protection.
These sensors operate efficiently within a wide voltage range of 10 to 30VDC, with a low no-load supply current of ?30mA and a load current capacity of ?100mA. The response time is a swift 500µs, and the switching frequency reaches up to 1kHz, ensuring rapid and accurate detection. The sensors are also equipped to handle interference from external light sources, with a tolerance of up to 3,000 lux from incandescent lamps and 10,000 lux from sunlight.
The compact design, with dimensions of 21.4mm x 90mm and a weight of 100g, allows for easy installation in tight spaces. The M12 plug connection at a 90° angle facilitates straightforward integration into existing systems. The SAT/0P-1K Sensors are CE approved and comply with EMC compatibility standards EN 60947-5-2, ensuring reliable performance in various industrial settings. Supplied with M18 x 1 nuts, these sensors are ready for immediate deployment, offering a dependable solution for precise and efficient sensing needs.
- Nominal sensing distance:
- 12mm
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- PNP L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green (powerON), Yellow (Status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 100g
- Housing Material:
- Nickel-plated brass / Nylon plug
- Connections:
- M12 plug 90°
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
