Datasensing SH2/E-1EIC Sensors

The Datasensing SH2/E-1EIC Sensors are designed for optimal safety and reliability in industrial environments. These Type 2 safety photocell emitters feature a robust M18 metal housing with an axial connection and M12 I/O interface, ensuring compatibility with IEC61131-2 standards. With a nominal sensing distance of 10 meters and a thermal drift of Sr ? 10%, these sensors provide precise single-beam resolution and controlled height detection. The effective aperture angle is ? ±5°, with a typical value of ±1.8°, ensuring accurate detection across various applications. Operating at a frequency of 123 kHz, the SH2/E-1EIC sensors are equipped with LED indicators for easy status monitoring, including a yellow power indicator and red emission signal. The sensors operate within a voltage range of 10 to 30 Vdc, with a no-load supply current of ? 25mA and a maximum ripple content of ? 5 Vpp. The emission is inactive below 5V and active above 15V, providing reliable performance in diverse conditions. Constructed with a durable PBT housing and glass active head material, these sensors are designed to withstand harsh environments, with an operating temperature range of -20°C to +55°C and storage temperature range of -40°C to +75°C. They are CE and TÜV approved, offering IP67 mechanical protection against dust and water ingress. The sensors are also resistant to shocks and vibrations, meeting IEC60068-2-29 and IEC60068-2-6 standards. Please note that these sensors are not compatible with the SBCR03 control unit and should be used with an external safety control unit featuring an automatic optics test function. Supplied with two nuts for easy installation, the Datasensing SH2/E-1EIC Sensors are an ideal choice for creating a compliant safety system in accordance with EN ISO 13849 standards.
