Datasensing SH4/R-1EIA Sensors
Datasensing
$154.04
The Datasensing SH4/R-1EIA Sensors are advanced safety sensor receivers designed for high-performance industrial applications. Featuring a robust M18 metal housing, these sensors offer a nominal sensing distance of 10 meters with an axial connection and are compliant with IEC61131-2 standards. They are engineered to work seamlessly with the SBCR03 control unit, ensuring a reliable safety system that meets EN ISO 13849 standards.
These Type 4 safety photocell receivers boast a single-beam resolution and an effective aperture angle of ? ±2.5°, making them ideal for precise safety applications. With a SIL rating of 3 and a performance level (PL) of 'e', they provide exceptional safety integrity and reliability, with a PFHd of 8.10E-10 and an MTTFd of 20 years.
The sensors operate within a voltage range of 10 to 30 Vdc, with a no-load supply current of ? 25mA and a load current of ? 70mA. They feature a totem-pole output type, designed to connect directly to the SBCR03 control unit, and offer rapid response times of 200µs for light/dark transitions and 400µs for dark/light transitions.
Constructed with a durable PBT housing and a glass active head, these sensors are built to withstand harsh environments, with an operating temperature range of -20°C to +55°C and a storage temperature range of -40°C to +75°C. They are IP67 rated for mechanical protection and are approved by CE and TÜV, ensuring compliance with international safety standards.
The sensors come equipped with yellow LED indicators for alignment, and are supplied with two nuts for easy installation. With their high resistance to shocks and vibrations, these sensors are an ideal choice for maintaining safety in demanding industrial settings.
- Nominal sensing distance:
- 10m (ExG=4)
- Thermal drift of Sr:
- ? 10%
- Resolution:
- Single-beam
- controlled height:
- Single-beam
- Effective Aperture Angle:
- ? ±2,5°
- Effective Aperture Angle:
- Typical ±1,8°
- Function Principle:
- Receiver
- Control unit to be used:
- SBCR03
- Description:
- M18 Type 4 Safety Photocell Receiver
- Type:
- Type 4 safety photocell
- SIL:
- 3
- SILCL:
- 3
- PL:
- e
- PFHd:
- 8,10E-10
- MTTFd:
- 20 years
- Output type:
- Totem-pole
- Output Function:
- To be connectred to SBCR03
- Resposnse time for light/dark transition:
- 200µs
- Resposnse time for dark/light transition:
- 400µs
- Operating Voltage:
- 10 30 Vdc
- No-Load supply current:
- ? 25mA
- Load current:
- ? 70mA
- Output voltage drop:
- 2,5V @ 50mA
- Max ripple content:
- ? 5 Vpp
- LED indicators:
- Yellow (alignement)
- Housing Material:
- PBT
- Connections:
- M12 plug
- Active Head Material:
- Glass
- Operating temperature:
- -20°C +55°C
- Storage temperature:
- -40°C +75°C
- Approvals:
- CE, TÜV
- Shocks and vibrations:
- 10g - 16ms (according to IEC600068-2-29) 10Hz 55Hz - 1 oct/min - 0,35mm (according to 60068-2-6)
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 x nuts
- Operating Temperature:
- -20 +55°C (Without freeze)
- Mechanical Protection:
- IP67
