The Datasensing SS1/0P-0A Sensors are designed for precision and reliability, featuring a nominal sensing distance of 100mm and a repeat accuracy of 5%. These sensors utilize a blackground suppression function principle, ensuring accurate detection with a minimum detectable object size of 3.5mm. The optic position is axial, and the output type is PNP L/D selectable, providing flexibility in various applications. With a switching frequency of 1kHz and a response time of 500µs, these sensors are ideal for high-speed operations.
Built to withstand harsh environments, the SS1/0P-0A Sensors offer complete protection against electrical damages, including short-circuit and reverse polarity protection. They are housed in a robust PBT/PC material with an IP67 protection degree, ensuring durability and resistance to dust and water. The sensors are equipped with a yellow LED status indicator for easy monitoring and are compatible with ATEX models, category 3, upon request.
Operating within a voltage range of 10
30VDC, these sensors have a no-load supply current of ? 30mA and a load current of ?100mA. They are designed to handle impulsive overvoltage and have a low output voltage drop of ?1.2V at a load of 100mA. The sensors are EMC compatible with EN 60947-5-2 standards and can operate in temperatures ranging from -25°C to +70°C without freezing.
The Datasensing SS1/0P-0A Sensors come with supplied accessories, including nuts M18 x 1, and feature a 2m PVC cable for easy installation. With approvals from CE and cULus, these sensors are a reliable choice for various industrial applications.
- Nominal sensing distance:
- 100mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- minimum detectable object:
- 3,5mm
- Sensitivity adjustment:
- No
- Function Principle:
- Blackground suppression
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- PNP L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 70g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
