Datasensing SSU/00-0E Sensors
Datasensing
$95.73
The Datasensing SSU/00-0E Sensors are designed for precision and reliability in various industrial applications. Featuring a nominal sensing distance of 3m for the SSU model, these sensors offer exceptional performance with a thermal drift of Sr ?10% and a repeat accuracy of 5%. The emitter operates on a 10
30VDC voltage range, with a no-load supply current of ? 25mA and a maximum ripple content of ?10%.
Equipped with a yellow LED indicator for power status, these sensors ensure easy monitoring and diagnostics. The robust design includes complete protection against electrical damages, with short-circuit, reverse polarity, and impulsive overvoltage protection. The IP67 protection degree guarantees durability in harsh environments, while the ATEX models, category 3, are available upon request for explosive atmospheres.
The sensors feature an axial optic position and are housed in a durable PBT/PC plug with an active head made of PMMA. The M18 x 1 dimensions and a weight of 30g make them compact and easy to install, with a tightening torque of 1Nm. Operating efficiently in temperatures ranging from -25°C to +70°C, these sensors are CE and cULus approved, ensuring compliance with international standards. The package includes M18 x 1 nuts for secure mounting, making the Datasensing SSU/00-0E Sensors a reliable choice for your sensing needs.
- Nominal sensing distance:
- 3m (SSU), 8m (SSG)
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter
- Emitter/Receiver:
- Emitter
- Optic position:
- Axial
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow(powerON)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
