Datasensing UK1C/G6-1ASY Sensors
Datasensing
$440.36
The Datasensing UK1C/G6-1ASY Sensors are high-performance ultrasonic sensors designed for precise and reliable distance measurement. Featuring an M18 analog design, these sensors offer a nominal sensing distance of 900mm with a thermal drift of ±2% and a repeat accuracy of 0.50%. The beam angle is 10° ± 2°, ensuring focused detection, while the resolution is ?3mm for accurate readings.
Equipped with a teach-in button, the sensors allow for easy sensitivity adjustment and working area configuration, whether through window teach or single point teach. The adjustable hysteresis function, with a 1% margin, is ideal for applications requiring programmable double digital outputs, specifically for level detection.
The sensors provide both current and voltage analogue outputs, with a PNP output type and a 4-20 mA range. They support NO/NC output functions with positive/negative slope options, and a switching frequency of 4Hz. The response time is a swift 500ms, and they operate on a voltage range of 10 - 30Vdc, with a no-load supply current of ?50mA and a load current of 100mA.
Built with a robust AISI316L stainless steel housing, these sensors are designed to withstand harsh environments, offering IP67 mechanical protection. They are equipped with short-circuit, reverse polarity, and impulsive overvoltage protection, ensuring durability and reliability. The sensors come with a 2m PVC cable for easy installation and are approved by CE and cULus standards, with EMC compatibility according to IEC 60947-5-2.
The multifunction LED indicators provide clear status updates, with green indicating echo and yellow for output. The sensors are designed to handle operating temperatures from -20°C to +70°C and can be stored in temperatures ranging from -35°C to +80°C without freezing. With a transducer frequency of 300kHz and a compact M18 x 1 / L = 83.6mm dimension, these sensors are ideal for a wide range of industrial applications. Supplied accessories include two M18x1 nuts and two Ø 18 washers for secure mounting.
- Nominal sensing distance:
- 900mm
- Thermal drift of Sr:
- ±2%
- Repeat Accuracy:
- 0,50%
- Beam angle:
- 10° ± 2°
- Resolution:
- ?3mm
- Sensitivity adjustment:
- Teach-in button
- Hysteresis:
- 1%
- thermal compensation:
- Yes
- Minimum sensing distance (blind zone):
- 100mm
- Linearity error:
- 1%
- Function Principle:
- Diffuse reflection
- Output type:
- PNP + 4...20mA
- Output Function:
- NO/NC + positive/negative slope
- Switching frequency:
- 4Hz
- Response time:
- 500ms
- Operating Voltage:
- 10 - 30Vdc
- No-Load supply current:
- ?50mA
- Load current:
- 100mA
- Leakage current:
- 10?A @ 30Vcc
- Output voltage drop:
- 2,2Vmax. @ IL=100 mA
- Max ripple content:
- 5%
- LED indicators:
- green: echo - yellow: output
- Time delay before availability:
- ?300ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 170g
- Housing Material:
- stainless steel AISI 316L
- Connections:
- 2m PVC Cable
- Tightening torque:
- 50Nm
- Storage temperature:
- - 35°C + 80° C without freeze
- Transducer Frequency:
- 300kHz
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- IEC EN60947-5-2 / 7.4
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M18x1, 2 washers Ø 18
- Mechanical Protection:
- IP67
