Ultras.cubico NPN + 4..20mA usc. conn. M12
- Nominal sensing distance:
- 1200mm
- Thermal drift of Sr:
- ±5%
- Resolution:
- 3mm
- Sensitivity adjustment:
- Teach-in button
- Hysteresis:
- 1%
- thermal compensation:
- Yes
- Minimum sensing distance (blind zone):
- 80mm
- Linearity error:
- 1%
- Effective Aperture Angle:
- 8° ± 2°
- Function Principle:
- Diffuse reflection
- Output type:
- NPN + 4...20mA
- Output Function:
- NO/NC + positive/negative slope
- Switching frequency:
- 3Hz
- Response time:
- 400ms
- Operating Voltage:
- 10 - 30Vdc
- No-Load supply current:
- ?35mA
- Load current:
- 100mA
- Leakage current:
- 10?A @ 30Vcc
- Output voltage drop:
- 2,2Vmax. @ IL=100 mA
- Max ripple content:
- 5%
- LED indicators:
- verde: echo - giallo: uscita
- Short-circuit protection:
- si
- Reverse Polarity Protection:
- si
- Impulsive Overvoltage Protection:
- si
- Connections:
- M12 Plug
- Tightening torque:
- 1Nm
- Storage temperature:
- - 35°C + 80° C senza ghiaccio
- Transducer Frequency:
- 200kHz
- Material:
- PBT
- Diameter/Dimension:
- Cubic
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- IEC EN60947-5-2 / 7.4
- Degree of protection:
- IP67
- Supplied Accessories:
- 1 M18x1 nut
- Mechanical Protection:
- IP67
