The Datasensing UT1B/GW-1ESYIO Sensors are advanced M30 ultrasonic sensors designed for high-performance applications with a wide sensing range of 250-3500 mm. Featuring a robust AISI316L stainless steel housing, these sensors are equipped with an adjustable hysteresis function and a standard window mode, making them ideal for precise level detection. The sensors offer dual digital programmable outputs (NO+NC) and support IO-Link communication, ensuring seamless integration into various systems.
Installation is simplified with the Teach-in button, allowing for quick adjustments to the working area, whether in window mode or object mode. The sensors are equipped with two multifunction LEDs: an orange LED for adjustment procedures and output type indication, and a green LED for target alignment, enhancing user interaction and setup efficiency.
The M12 connection ensures secure and reliable connectivity, while the sensor's design includes protection features such as short-circuit, reverse polarity, and impulsive overvoltage protection. With a durable construction that withstands harsh environments, these sensors are cULus approved and offer excellent EMC compatibility, making them suitable for a wide range of industrial applications.
- Sensitivity adjustment:
- Teach-in button
- Function Principle:
- Diffuse reflection
- Output type:
- IO-Link/ 2x PNP
- Output Function:
- NO/NC multifunctions
- Connections:
- M12 Plug
- Diameter/Dimension:
- M30
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- Catalog:
- View
- User Manuals:
- View
- Software:
- View
- Quick References:
- View" target="_blank">View
